It is used to filter the plastics and remove the foreign matters and impurities.
1. Double die head design, easy to change the filter screen.
2. Strong and safe, easy to repair and maintain.
3. The surface of screw and barrel has been specially treated, which is wear-resistant and corrosion-resistant.
|
型號(hào) Model |
SJL200 | SJL250 | SJL300 | SJL350 | |
|---|---|---|---|---|---|
|
螺桿直徑 (mm) Screw diameter |
200 | 250 | 300 | 350 | |
|
電機(jī)功率 (kw) Motor power |
75 | 110 | 132 | 185 | |
|
生產(chǎn)能力 (kg/h) Production capacity |
800-1000 | 1200-1500 | 1400-1800 | 3000 | |
|
外形尺寸(mm) Overall dimension |
長(zhǎng)(L) | 3300 | 3700 | 4700 | 5100 |
| 寬(W) | 1400 | 1600 | 1800 | 2000 | |
| 高(H) | 1800 | 1900 | 2000 | 2100 | |
|
重量(t) Weight |
11 | 13 | 15 | 18 | |
