It is mainly used for once continuous coating or rubbing of tyre fiber cord .
|
型號 Model |
XY-4F1550 | XY-4F610*1730 | XY-4S510*1450 | XY-4S610*1730 | XY-4S660*1850 |
|---|---|---|---|---|---|
|
輥筒直徑 Roll diameter |
560 | 610 | 510 | 610 | 660 |
|
輥筒工作長度 Roll working length |
1550 | 1730 | 1450 | 1730 | 1850 |
|
驅動輥線速度(m/min) Drive roll liner speed |
3.5～35 | 5.4～54 | 3～30 | 6～60 | 7～70 |
|
制品寬度 Max.product width |
1300 | 1500 | 1200 | 1500 | 1600 |
|
制品小厚度 Min.product thickness |
0.2 | 0.2 | 0.2 | 0.2 | 0.2 |
|
電機功率 Motor power |
185 | 220 |
45X2 55X2 |
90X2 110X2 |
110X2 132X2 |
